The Vivitek DX255 is a 3,200 ANSI Lumens high XGA digital projector from Vivitek. It is compact and lightweight at less than 2kg for easy portability, and it comes with a long lamp life up to 8,000 hours
| Native Resolution | XGA (1024 x 768) |
| Brightness | 3200 ANSI Lumens |
| Contrast Ratio | 10,000:1 |
| Max. Supported Resolution | 1080p (1920 x1080) @60Hz |
| Native Aspect Ratio | 4:3 |
| Lamp Life and Type | 4,000/6,000/8,000 Hours (Normal/Eco./Dynamic Eco. Mode), 203W/170W |
| Display Type | Single chip DLP® Technology by Texas Instruments |
| Chip Size | 0.55” DMD |
| Throw Ratio | 1.97 - 2.17:1 |
| Image Size (Diagonal) | 27" - 290" |
| Projection Distance | 1.2 - 11m |
| Projection Lens | F = 2.51 - 2.69, f = 21.95 - 24.18mm |
| Zoom Ratio | 1.1x |
| Offset (Based on Full Image Height) | 115% |
| Keystone Correction | Vertical +/-40° |
| Speakers | 2W |
| Video Compatibility | SDTV (480i, 576i), EDTV (480p, 576p), HDTV (720p, 1080i/p), NTSC (M, 3.58/4.43 MHz), PAL (B, D, G, H, I, M, N), SECAM (B, D, G, K, K1, L) |
| I/O Connection Ports | VGA-In (15pin D-Sub), HDMI, Composite Video, Audio-In (Mini-Jack), Audio-Out (Mini-Jack), RS-232, USB miniB (Service) |
| Dimensions (W x D x H) | 285 x 193.5 x 111.5mm |
| Weight | 1.97 kg |
| Noise Level | 30dB/28dB (Normal/Eco. Mode) |
| Power | Supply: AC 100-240V, 50/60Hz Consumption: 220W (Eco. Mode), 260W (Normal Mode), <0.5W (Standby) |
| 3D Ready(DLP link, PC+Video) | Yes |
| Spare Lamp P/N | XX5050000500 |
| Remote Control P/N | XX5040001900 |
| Standard Accessories | VGA Cable, User Manual (CD), Quick Start Guide, Warranty Card (by region), Remote Controller (with battery), AC Power Cord |
| Optional Accessories | Spare Lamp P/N: XX5050000500 , Remote Control P/N: XX5040001900 , Carrying Case P/N |
| Warranty | Entry Warranty: 2 years projector / 1 year on lamp or 1000 hours whichever comes first |
| UPC Code | 813097 021908 |
